Policy Gradient for LLMs, Explained Visually

Most RL algorithms used to train language models, from PPO to GRPO, are elaborations of one idea: the policy gradient. This post derives it from scratch for an LLM solving a problem with a checkable answer. It follows one prompt, “What is 17 × 24?”, from next-token probabilities to the gradient that makes correct answers more likely.

Language models as policies

Given a prompt $x$, a language model generates a completion $y = (y_1, \dots, y_T)$ one token at a time. In RL terms, the model is a policy: at each step it looks at the prefix it has produced so far and outputs a distribution over the next token, from which one token is sampled.

The probability of the full completion is the product of the per-token probabilities:⊕$\theta$ is the model’s parameters: its weights, which training adjusts.

$$p_\theta(y \mid x) = \prod_{t=1}^{T} p_\theta(y_t \mid x, y_{<t})$$

Generating a completion traces one path through a tree of possible continuations.⊕Each $p(\cdot)$ in the tree is conditioned on the prompt and on every token before it on the path, so $p(24)$ means $p(24 \mid x, 17, \times)$. The slot from the previous figure is one branch point: 68 leads to the correct answer, and the 58 slip to a wrong one. Once the model emits a stop token, a reward function grades the finished completion.

For reasoning tasks, the reward function is often a verifier that returns $R(x, y) = 1$ if the final answer is correct and $0$ otherwise.⊕This setup is often called RL with verifiable rewards (RLVR). Math problems with a known answer and coding tasks with unit tests are common examples. Our goal is to find the parameters $\theta$ that maximize the expected reward, which we call the objective $J(\theta)$:Read the objective as: draw a prompt $x$ from the training set $\mathcal{D}$, let the model generate a completion $y$, compute its reward, and average over many such draws. The letter $J$ comes from optimal control, where it names a cost to minimize. RL borrowed it for a reward to maximize, which is why it isn’t $L$, the usual letter for a loss.

$$J(\theta) = \mathbb{E}_{x \sim \mathcal{D}, \; y \sim p_\theta(\cdot \mid x)}\big[R(x, y)\big]$$

This is the standard reinforcement learning objective.In general RL, an agent collects a reward after each of many actions, and the objective is the expected total reward over an episode, often discounted. Generating a completion is an episode where each token is an action and the only reward comes at the end, so the total is just $R(x, y)$.

From here on, I’ll drop the prompt $x$ from the notation; everything is conditioned on it.

The policy gradient

To improve the model, we want to follow the gradient of the objective, $\nabla_\theta J(\theta)$: the direction in parameter space that most increases the expected reward. This gradient is the policy gradient,The name is short for the gradient of expected reward with respect to the policy’s parameters. It contrasts with value-based methods like Q-learning, which learn how good each action is and act on those estimates instead of adjusting the policy directly. The term became standard with Sutton et al. (2000). and methods that train by estimating and following it are called policy gradient methods. REINFORCE, PPO, and GRPO are all examples. They share this expected-reward goal, but PPO and GRPO also change the update itself, clipping or reweighting it to keep training stable.

The hard part is computing it. Written out, the objective is a sum over every possible completion:

$$J(\theta) = \sum_y p_\theta(y) \, R(y)$$

$\theta$ appears only in $p_\theta(y)$, how likely each completion is, and not in the reward $R(y)$. If we could evaluate this sum, we could differentiate it directly, but there are far too many completions to enumerate.⊕With a vocabulary of about 150,000 tokens, even a 100-token completion has more than $10^{500}$ possibilities.

The usual fix for an expectation we can’t enumerate is to estimate it by sampling: generate $N$ completions, compute their rewards, and average them. That gives a fine estimate of $J$, but not one we can differentiate. The completions are discrete token sequences,At each step, the model’s probabilities define a categorical distribution over the vocabulary, and we draw one token from it. The result is an integer token ID: a small change to $\theta$ either leaves it unchanged or flips it, so there is no smooth gradient. (Sampling often reshapes the distribution with a temperature or top-p cutoff. The derivations here assume we sample from the model’s probabilities as-is.) and their rewards come from a verifier, a unit test, or a person, none of which we can backpropagate through. There is no path for autograd to follow from the reward back to $\theta$.

Compare supervised fine-tuning, where the completion $y$ is fixed training data and $\theta$ appears directly in the loss $-\log p_\theta(y)$. Here, $\theta$ decides which completions we get, not how any one of them is graded. What we need is a way to rewrite $\nabla_\theta J$ as an average, over sampled completions, of something we can differentiate.

The log-derivative trick

The workaround is a one-line identity, $\nabla_\theta p_\theta = p_\theta \nabla_\theta \log p_\theta$,⊕By the chain rule, $\nabla_\theta \log p_\theta = \nabla_\theta p_\theta / p_\theta$. Multiply both sides by $p_\theta$. which moves the gradient inside the expectation:

$$\begin{aligned} \nabla_\theta J(\theta) &= \nabla_\theta \, \mathbb{E}_{y \sim p_\theta}\big[R(y)\big] \\ &= \nabla_\theta \sum_y p_\theta(y) \, R(y) \\ &= \sum_y \underbrace{\nabla_\theta p_\theta(y)}_{\mathclap{\text{depends on } \theta}} \, R(y) \\ &= \sum_y \underbrace{p_\theta(y) \, \nabla_\theta \log p_\theta(y)}_{\mathclap{\text{the identity}}} \, R(y) \\ &= \mathbb{E}_{y \sim p_\theta}\big[R(y) \, \underbrace{\nabla_\theta \log p_\theta(y)}_{\mathclap{\text{the score}}}\big] \end{aligned}$$

The quantity $\nabla_\theta \log p_\theta(y)$ is called the score.Don’t read much into the word: it doesn’t rate how good a completion is. The name comes from statistics, where $\nabla_\theta \log p$ is the score function of maximum-likelihood estimation. REINFORCE is sometimes called the score-function estimator for the same reason. It points in the direction in parameter space that most increases the log-probability of the completion $y$. The final line is an expectation over completions sampled from the policy $p_\theta$ itself,This is the language-model case of the policy gradient theorem (Sutton et al., 2000). In general RL, it reads $\nabla_\theta J = \mathbb{E}\big[\sum_t Q^\pi(s_t, a_t)\, \nabla_\theta \log \pi_\theta(a_t \mid s_t)\big]$ ($\pi_\theta$ is the usual RL notation for the policy $p_\theta$), where $Q^\pi(s_t, a_t)$ is the expected future reward after taking action $a_t$ in state $s_t$. For a completion, the state is the prefix and the action is the next token. With only a final reward, $Q^\pi$ is the expected reward of finishing from that prefix, and the sampled $R$ is a one-sample estimate of it. so we can estimate it by sampling. Perform $N$ rollouts (that is, draw $N$ completions from the policy), score each one, and average:

$$\nabla_\theta J(\theta) \approx \frac{1}{N} \sum_{i=1}^{N} R(y_i) \, \nabla_\theta \log p_\theta(y_i), \qquad y_i \sim p_\theta$$

This is the REINFORCE estimator,Introduced by Ronald Williams in Simple Statistical Gradient-Following Algorithms for Connectionist Reinforcement Learning (1992). PPO, GRPO, DAPO, and most other RL algorithms used for LLMs today are elaborations of this estimator. also known as the Monte Carlo policy gradient: it estimates the gradient by averaging over complete sampled rollouts, using each one’s actual reward rather than a learned estimate of how good it was.It is unbiased: averaged over many batches, it equals the true gradient. Any single batch, though, can point well away from it. Each term pairs a direction with a weight: the score points toward making that rollout’s completion more likely, and the reward sets how much that direction counts.

Because all completions share a total probability of 1, A’s and C’s gains come from elsewhere, here mostly from completions nobody sampled. B barely changes, because it shares everything up to “340 +” with A, so reinforcing A also lifts most of B’s path. The numbers are only illustrative: A and C are pushed up, but how every other completion moves depends on how the model’s parameters are shared.

With the reward held fixed, $R \, \nabla_\theta \log p_\theta(y)$ is exactly the gradient of $R \log p_\theta(y)$: a log-likelihood on one of the model’s own samples, weighted by its reward. So policy gradient is supervised fine-tuning on your own samples, weighted by reward. With $+1/0$ rewards, as in the figure above, it is literally SFT on the correct completions, so incorrect completions are never pushed down directly; they only lose share.Training on your own correct samples is also used on its own, as rejection-sampling fine-tuning or expert iteration. STaR is an early example for reasoning.

From sequences to tokens

A completion’s log-probability is a sum of per-token log-probabilities, so its score breaks into one term per token:

$$\nabla_\theta \log p_\theta(y) = \sum_{t=1}^{T} \nabla_\theta \log p_\theta(y_t \mid y_{<t})$$

Each term is the score of a single token: the direction that most increases the probability of choosing $y_t$, given everything generated before it. So we can study the update one position at a time. Pick a single position, such as the slot right after “340 +” in the 17 × 24 example, and hold its prefix $y_{<t}$ fixed. For each token $v$ in the vocabulary, write

$$p_v = p_\theta(v \mid y_{<t}) \qquad \text{and} \qquad s_v = \nabla_\theta \log p_v$$

for the model’s probability of choosing $v$ at this position and that token’s score. In the example, $p_{68} = 0.82$ and $p_{58} = 0.07$.

Only one token is actually sampled at each position. Its contribution to the update is $R \, s_{y_t}$: that token’s score, multiplied by the reward the whole completion earned.

To see what a token’s score looks like, look at the last layer. At one position, the network outputs a logit $z_u$ for every token $u$ in the vocabulary, and $p = \operatorname{softmax}(z)$. Differentiating the log-softmax gives the logit gradient of the chosen token $v$:

$$\log p_v = z_v - \log \sum_u e^{z_u} \qquad\Longrightarrow\qquad \frac{\partial \log p_v}{\partial z_u} = \begin{cases} 1 - p_v & u = v \\ -p_u & u \neq v \end{cases}$$

It is positive on the chosen token’s own logit, negative on every other logit in proportion to that token’s probability, and sums to zero. The score is this vector carried back through the network to the parameters by the chain rule:

$$s_v = \sum_u \big(\mathbb{1}[u = v] - p_u\big) \, \nabla_\theta z_u$$

As $p_v \to 1$, every coefficient in this sum goes to zero, so the score does too. Across completions A and B from the figure above:

The reward only says whether the finished completion was right, so every position gets the same $R$, whatever its token did:This is the credit assignment problem. Methods that learn a value function, or use process reward models that grade intermediate steps, try to give individual tokens their own credit. B’s correct opening steps get nothing, and A’s filler tokens get the full reward. What differs from token to token is the score, which is tiny for tokens the model was already sure of.The actual step also scales with the learning rate and depends on how the network maps parameters to logits, and a token’s probability can still change because of other tokens’ gradients.

The score has zero mean

The score has a simple but important property. On-policy, when the token is sampled from the same distribution $p$ whose score we compute, the expected score is exactly zero:

$$\begin{aligned} \mathbb{E}_{y_t \sim p}[s_{y_t}] &= \sum_v p_v \, \nabla_\theta \log p_v = \sum_v \nabla_\theta p_v \\ &= \nabla_\theta \sum_v p_v = \nabla_\theta 1 = 0 \end{aligned}$$

Intuitively, probability is conserved. Any change to $\theta$ that makes some tokens more likely must make others less likely by the same total amount. Weighted by how often each token is sampled, the pushes cancel.

We can check this at the logits. In vector form, the logit gradient from the previous section is $e_v - p$, where $e_v$ is the one-hot vector for $v$; the zoom-ins in the figure above show it for 68 and for “=”. Averaging these vectors over which token gets sampled, weighted by $p$, gives $\sum_v p_v (e_v - p) = p - p = 0$.

Baselines and group centering

Nothing so far required the rewards to be $+1/0$. What if we use $+1/-1$ instead? That doubles every reward and then subtracts 1. Doubling just doubles the gradient. For the shift, the zero-mean identity is the answer: we can subtract any baseline $b$ from the reward without changing the expected gradient, as long as $b$ does not depend on the sampled token:

$$\mathbb{E}_{p}\big[(R - b) \, s_{y_t}\big] = \mathbb{E}_{p}[R \, s_{y_t}] - b \, \underbrace{\mathbb{E}_{p}[s_{y_t}]}_{=\,0} = \mathbb{E}_{p}[R \, s_{y_t}]$$

The quantity $A = R - b$ is called the advantage. Subtracting a baseline adds no bias: REINFORCE stays unbiased, with exactly the same expected gradient. What it can change is the variance, and a well-chosen baseline reduces it dramatically.See Greensmith, Bartlett, and Baxter (2004) for a thorough treatment of baselines as variance reduction for policy gradient estimates. To see why, split each rollout’s term in two:

$$R \, s_{y_t} = \underbrace{b \, s_{y_t}}_{\text{mean zero, but noisy}} + \underbrace{(R - b) \, s_{y_t}}_{\text{the advantage-weighted part}}$$

The first part contributes nothing to the expected gradient, but each sample of it is a large vector pointing somewhere different. In the extreme case where every completion earns $R = 1$, the true gradient is zero, yet each sample still pushes its own log-probabilities up at random. With $b = 1$, every term vanishes. How much a baseline helps depends on $b$. The standard choice is the prompt’s expected reward. It isn’t exactly optimal,The variance depends on $b$ only through $\mathbb{E}\big[(R - b)^2 \lVert s \rVert^2\big]$, which is minimized at $b^\star = \mathbb{E}\big[R \lVert s \rVert^2\big] / \mathbb{E}\big[\lVert s \rVert^2\big]$. This is close to $\mathbb{E}[R]$ only when the reward is roughly unrelated to the size of the score. They can differ a lot: for a binary choice that succeeds with probability 0.1, successes have the larger score, so $b^\star = 0.9$ while $\mathbb{E}[R] = 0.1$. but it is simple to estimate, and because some prompts are far easier than others, estimating it per prompt removes a large source of noise.

GRPOIntroduced in DeepSeekMath. GRPO also divides by the group’s reward standard deviation. Dr. GRPO argues that this normalization introduces a bias toward easy and hard prompts. Here I use mean-centering only. Because the group mean includes the completion’s own reward, the expected gradient is scaled by $1 - 1/G$. When every prompt uses the same $G$, that is just a slightly smaller step size. A leave-one-out baseline, as in RLOO, removes the factor. popularized a simple, critic-freeA critic is a second network trained to predict the expected reward, the value $V(x)$, to use as the baseline. PPO usually trains one alongside the policy. GRPO replaces it with the group’s mean reward, which saves a model of similar size to the policy. baseline for LLMs: sample a group of $G$ completions for each prompt and use the group’s mean reward as the baseline for each of them:

$$A_i = R_i - \frac{1}{G} \sum_{j=1}^{G} R_j$$

Correct completions now get a positive advantage and are reinforced. Incorrect completions get a negative advantage and are suppressed. Prompts where every completion succeeds, or every completion fails, contribute nothing. For the four rollouts from earlier:

REINFORCE with group-centered advantages fits in a few lines of PyTorch:

def reinforce_loss(logprobs, rewards, mask, group_size):
    # logprobs: (B, T) per-token log p_θ(y_t | y_<t)
    # rewards:  (B,)   one per completion, grouped by prompt
    # mask:     (B, T) 1 on completion tokens, else 0
    r = rewards.view(-1, group_size)
    advantages = (r - r.mean(dim=1, keepdim=True)).view(-1)
    seq_logprobs = (logprobs * mask).sum(dim=1)  # log p_θ(y)
    return -(advantages * seq_logprobs).mean()

The advantages are constants that carry no gradient, so differentiating this loss gives exactly the estimator from the previous sections, with advantages in place of rewards.Many implementations instead divide the summed loss by the total number of completion tokens in the batch. That changes more than the scale: the denominator varies with the sampled lengths, so it reweights completions by length. Dr. GRPO discusses this bias. PPO, GRPO, DAPO, and most other RL algorithms used for LLMs start from this loss and add clipping, masking, or reweighting.

The on-policy assumption

Both identities in this post, the log-derivative rewrite and the zero-mean score, assume that the completions are sampled from the same distribution $p_\theta$ that we differentiate. In the rewrite, $p_\theta$ is both the distribution we average over and the model we differentiate. In the zero-mean identity, averaging over $p$ itself is what makes the pushes cancel. If the samples come from even a slightly different distribution, the expected score is no longer guaranteed to be zero, and subtracting a baseline shifts the expected gradient instead of leaving it unchanged.

In practice, this assumption rarely holds exactly. In the reinforce_loss above, logprobs comes from the training framework’s forward pass, but the completions were generated by a separate inference engine, such as vLLM or SGLang. The two are supposed to compute the same distribution, but they seldom do. They can run at different numerical precisions, and in asynchronous setups the inference engine may still be serving weights from a few updates ago. Either way, the completions come from a slightly different model than the one being trained. That gap is where the trouble starts.

Further reading

• OpenAI Spinning Up: Intro to Policy Optimization derives the same policy gradient in general RL notation, including the expected grad-log-prob lemma, which is the zero-mean identity above.
• Lilian Weng’s Policy Gradient Algorithms surveys the family, from REINFORCE through actor-critic methods and PPO.
• Andrej Karpathy’s Deep Reinforcement Learning: Pong from Pixels builds intuition for policy gradients by training a small network to play Pong.
• Nathan Lambert’s RLHF book covers policy gradient methods for language models, including PPO, GRPO, and RLOO.
